EB260A Swivel Head Metal Cutting Band Saw

Home Metal Working Machines Band Saws & Accessories Metal Band Saws - Horizontal B062

225 x 180mm (W x H) Rectangle Capacity

B062 1 of 11

Blade Tension Device 2 of 11

Control Panel 3 of 11

Feed Control Valve 4 of 11

Wire Wheel and Roller Bearing Blade Guides 5 of 11

Motor and Gearbox 6 of 11

Vice 7 of 11

Swivel Head Degree Scale 8 of 11

Quick Action Clamp Lever 9 of 11

Coolant System 10 of 11

Large Swarf Tray 11 of 11

Discontinued

Order Code: B062

240V / 10A
1 Year Warranty

Made in Taiwan

Compare

Wishlist

Description

225 x 180mm (W x H) Rectangle Capacity

225 x 180mm rectangular capacity
Larger cutting capacity than conventional cold saws
Heavy-duty gear drive system
Quick-action lock/release vice
Swivel head mitre cut to 60º right
Quick action lock/release lever for swivel head
Coolant system for cutting efficiency and blade life
Material support roller for long stock
User friendly blade tension system
Control panel mounted for easy access
Ball bearing blade guides ensures minimal blade clearance wear & increases blade life due to less friction
Blade cleaning brush incorporated into blade guide system
Adjustable hydraulic cylinder for auto feed
1-speed 240V motor enabling blade speeds of 90mpm
Vibration free, low noise operation ensures clean & high precision cuts
Machine stand with integrated cooling fitted as standard

Specifications

ORDER CODE	B062
MODEL	EB-260A (240V)
Operation Type	Swivel Head
(mm)Round @ 90º	225
(mm)Round @ 45º	150
(mm)Round @ 60º	100
(mm)Square @ 90º	180
(mm)Square @ 45º	160
(mm)Square @ 60º	100
(mm)Rectangle (W x H) @ 90º	225 x 180
(mm)Rectangle (W x H) @ 45º	140 x 140
(mm)Rectangle (W x H) @ 60º	100 x 100
Coolant System	Yes
(mm)Table Working Height	950
Cutting Head Beam Type	Manual
Cutting Head Beam Return	Manual Return
Cutting Head Down Feed Control	Adjustable Hydraulic
Vice Clamping Fixture	Manual - Quick Action
(m/min)Blade Steps / Speeds	90
(mm)Blade Size (L x W x T)	2480 x 27 x 0.9
(kW / hp)Motor Power	1.1 / 1.5
(V / amp)Voltage / Amperage	240
(kg)Nett Weight	216
