ORDER CODE | C3110 |
---|---|
MODEL | ORC-12-5 |
Drive Type | Direct |
(CFM / LPM)Piston Displacement | 4 / 113 |
(CFM / LPM)Free Air Delivery | 3.2 / 90 |
(Type)Cylinders | 1 |
(kPa)Max. Pressure | 1207 |
(PSI)Max. Pressure | 175 |
(Litre)Air Receiver Tank Size | 5 |
(kW / hp)Motor Power | 0.75 / 1 |
(V / amp)Voltage / Amperage | 12 |
(mm)Shipping Dimensions (L x W x H) | 370 x 350 x 320 |
(kg)Nett Weight | 15 |
